PD+QC fast charge configuration Intelligent recognition Support most of consumer electronics Full protections: SCP, OCP,OVP, OTP Type C connector Small and portable design Detachable pin design Polycarbonate housing
KEY APPLICATIONS
Mobile
phoneTablet
PCNotebook
Audio & Video product
INPUT
Input voltage：90～264Vac Frequency：50/60Hz±3Hz
OUTPUT
PD: 5V3A, 9V3A, 12V2.5A, 15V2A, 20V1.5A 30W max. PPS: 3-11V 30W max 3-16V 30W max Over voltage protection: The adapter shall resume normal operation when the fault condition is removed. Over current protection: It will automatically recover at 110-200% of rated load Short circuit protection: The adapter shall resume normal operation when the fault condition is removed. Operating temperature: 0℃~40℃ Non-Operating temperature: -40℃- +70℃
SAFETY STANDARDS
IEC/EN 62368 UL 62368
CERTIFICATES AND APPROVALS
UL CE CB
EMI EMISSION
Radiation & Conduction Test: EN 55032/FCC Part 15 Harmonic Test: EN 61000-3-2 Flicker Test: EN 61000-3-3
EMS IMMUNITY
ESD Test: EN 61000-4-2 RS Test: EN 61000-4-3 EFT Test: EN 61000-4-4 Surge Test: EN 61000-4-5 CS Test: EN 61000-4-6 DIP Test: EN 61000-4-11
