Light and portable High power density High compatibility
KEY APPLICATIONS
Mobile phone
Tablet PC
Audio & video product
Netcom product
Set top box
INPUT
Input voltage：90～264Vac Frequency：50/60Hz±3Hz
OUTPUT
Output voltage: 5V Output current: 0.01-2.1A Output power: 10.5W max Over voltage protection: The adapter shall resume normal operation when the fault condition is removed. Over current protection: It will automatically recover at 110-200% of rated load Short circuit protection: The adapter shall resume normal operation when the fault condition is removed. Operating temperature: 0~40℃ Operating humidity: 10%~90% RH Non-Operating temperature: -20℃~ +80℃
SAFETY STANDARDS
IEC/EN 60950-1 UL 60950-1 CSA C22.2 NO.950 GB4943.1 AS/NZS 60950.1
CERTIFICATES AND APPROVALS
CB,LVD, EMC, GS UL-CUL, FCC CCC SAA, RCM, GEMS
EMI EMISSION
Radiation & Conduction Test: FCC part 15, EN 55032, GB9254, GB17625.1. Harmonic Test: EN 61000-3-2 Flicker Test: EN 61000-3-3
EMS IMMUNITY
ESD Test: EN 61000-4-2 RS Test: EN 61000-4-3 EFT Test: EN 61000-4-4 Surge Test: EN 61000-4-5 CS Test: EN 61000-4-6 DIP Test: EN 61000-4-11
